Offset Field Description
36h
0
Hardware Radio Control.
0: disable hardware radio control (default value).
1: enable hardware radio control.
When “hardware radio control” bit is enabled (=1), the driver will read MAC’s
status. When GPIO pin is low, the radio is disabled. When GPIO
radio is enabled.
The Radio ON/OFF is controlled by both software UI and MAC’s GPIO pin.
1
TX power temperature compensation scheme enable (TC enable)
0 : disable temperature compensation
1 : Enable temperature compensation
This bit will disable/enable temperature compensation scheme.
While this bit is enable, it means Tx power TSSI scheme is disable(0x37 bit5 = 0)
and using TC scheme.
User must fill 0x53~0x54 and 0xF2~0xF5 for TC usage.
2
External 2.4GHz band LNA.
0: Board without external LNA for 2.4GHz band must set this bit to 0.
1: Board with external LNA for 2.4GHz band must set this bit to 1 (default value).
3
External 5GHz band LNA.
0: Board without external LNA for 5GHz band must set this bit to 0.
1: Board with external LNA for 5GHz band must set this bit to 1.
4
Proprietary TEST BIT.
For debug purpose. Default value is 0.
5
2.4GHz side band for 40MHz BW.
For debug purpose.
6
5G side band for 40M BW
For debug purpose.
7
WPS Push Button Configuration control.
0: disable WPS PBC control (default value).
1: enable WPS PBC control.
The WPS PBC function is controlled through GPIO[11].
If LED mode set to “Signal strength”(64), WPS PBC will be disabled.
37h 0
40M BW in 2.4GHz band.
0: enable 40MHz bandwidth for 2.4GHz band
1: disable 40MHz bandwidth for 2.4GHz band
