NIC Configuration 2 Register Bit Fields Description
Offset Field Description
42h
3:0
RX stream.
0 (0000): Reserved
1 (0001): 1 RX stream
2 (0010): 2 RX stream
3 ~ F (0011 ~ 1111): Reserved.
7:4
TX stream.
0 (0000): Reserved
1 (0001): 1 TX stream
2 (0010): 2 TX stream
3 ~ F (0011 ~ 1111): Reserved.
43h
0
Not support
2:1
Xtal option:
00 : reserved
01 : One crystal, enable co-clock out
10 : reserved
11 : reserved
3
25C Temperature disable bit
0 : Enable
1 : Disable
4
Reserved.
7:5
Reserved
Co-exist stream mode : default is 110
1 : 1x1 , no co-exist , Pure BT
2 : 1T2R, no co-exist , Pure WIFI
3 : 1T2R, no co-exist, Pure WIFI
4 : WLAN 1x1 and BT co-exist ,
5 : WLAN 2x2, no co-exist
6 : WLAN 2x2 and BT co-exist
