MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 8 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Offset
Default
(hex)
b15 ~b8 b7 ~ b0
78h
TX0 5G TX power offset low(Group4)
TX0 5G TX power(Group4) ( TSSI on )
TX0 5G TX ALC code (Group4) ( TSSI off )
7Ah
TX0 5G PA TSSI slope(Group5) TX0 5G TX power offset high(Group4)
7Ch
TX0 5G TX power(Group5) ( TSSI
on )
TX0 5G TX ALC code(Group5) ( TSSI
off )
TX0 5G PA TSSI offset (Group5)
7Eh
TX0 5G TX power offset high(Group5) TX0 5G TX power offset low(Group5)
80h
TX1 5G PA TSSI offset (Group0) TX1 5G PA TSSI slope(Group0)
82h
TX1 5G TX power offset low(Group0)
TX1 5G TX power(Group0) ( TSSI on )
TX1 5G TX ALC code (Group0) ( TSSI off )
84h
TX1 5G PA TSSI slope(Group1) TX1 5G TX power offset high(Group0)
86h
TX1 5G TX power(Group1) ( TSSI
on )
TX1 5G TX ALC code(Group1) ( TSSI
off )
TX1 5G PA TSSI offset (Group1)
88h
TX1 5G TX power offset high(Group1) TX1 5G TX power offset low(Group1)
8Ah
TX1 5G PA TSSI offset (Group2) TX1 5G PA TSSI slope(Group2)
8Ch
TX1 5G TX power offset low(Group2)
TX1 5G TX power(Group2) ( TSSI on )
TX1 5G TX ALC CODE(Group2) ( TSSI off )
8Eh
TX1 5G PA TSSI slope(Group3) TX1 5G TX power offset high(Group2)
90h
TX1 5G TX power(Group3) ( TSSI
on )
TX1 5G TX ALC CODE(Group3)
( TSSI off )
TX1 5G PA TSSI offset (Group3)
92h
TX1 5G TX power offset high(Group3) TX1 5G TX power offset low(Group3)
94h
TX1 5G PA TSSI offset (Group4) TX1 5G PA TSSI slope(Group4)
96h
TX1 5G TX power offset low(Group4)
TX1 5G TX power(Group4) ( TSSI on )
TX1 5G TX ALC CODE(Group4) ( TSSI off )
98h
TX1 5G PA TSSI slope(Group5) TX1 5G TX power offset high(Group4)
9Ah
TX1 5G TX power(Group5) ( TSSI
on )
TX1 5G TX ALC CODE(Group5)
( TSSI off )
TX1 5G PA TSSI offset (Group5)
9Ch
TX1 5G TX power offset high(Group5) TX1 5G TX power offset low(Group5)
9Eh
XTAL trim 2 Reserved
A0h
2.4G TX power for CCK 5.5M/11M 2.4G TX power for CCK 1M/2M
A2h
2.4G TX power for OFDM 12M/18M 2.4G TX power for OFDM 6M/9M
A4h
2.4G TX power for OFDM 48M/54M 2.4G TX power for OFDM 24M/36M
A6h
2.4G/5G TX power for HT/VHT
MCS=2,3
2.4G/5G TX power for HT/VHT MCS=0,1
A8h
2.4G/5G TX power for HT/VHT
MCS=6,7
2.4G/5G TX power for HT/VHT MCS=4,5
AAh
2.4G/5G TX power for HT MCS10,11 2.4G/5G TX power for HT MCS8,9
