MT7612
EEPROM Content
Confidential B
MediaTek Confidential
© 2013 MediaTek Inc.
Page 9 of 32
This document contains information that is proprietary to MediaTek Inc.
Unauthorized reproduction or disclosure of this information in whole or in part is strictly prohibited.
Offset
Default
(hex)
b15 ~b8 b7 ~ b0
ACh
2.4G/5G TX power for HT MCS14,15 2.4G/5G TX power for HT MCS12,13
AEh
Reserved
Reserved
B0h
Configured 2.4G Channels
Configured 2.4G Channels
B2h
5G Tx power for OFDM 12M/18M 5G Tx power for OFDM 6M/9M
B4h
5G Tx power for OFDM 48M/54M
5G Tx power for OFDM 24M/36M
B6h
Configured 5G Channels
Configured 5G Channels
B8h
Configured 5G Channels
Configured 5G Channels
BAh
Reserved Reserved
BCh
Reserved Reserved
BEh
TX power for 2.4G VHT MCS8,9
TX power for 5G VHT MCS8,9
F2h
5G ePA NT to low temp slope
5G ePA NT to high temp slope
F4h
2G ePA NT to low temp slope
2G ePA NT to high temp slope
F6h
TSSI off 2G TX power SKU (54M
dBm)
Reserved
F8h
RF0/1 2.4G RX High Gain (Group0)
TSSI off 5G TX power SKU (54M dBm)
FAh
RF0/1 5G RX High Gain (Group1)
RF0/1 5G RX High Gain (Group0)
FCh
RF0/1 5G RX High Gain (Group3)
RF0/1 5G RX High Gain (Group2)
FEh
RF0/1 5G RX High Gain (Group5)
RF0/1 5G RX High Gain (Group4)
130h
ASIC Reserved*
ASIC Reserved*
132h
ASIC Reserved*
ASIC Reserved*
134h
ASIC Reserved*
ASIC Reserved*
136h
ASIC Reserved*
ASIC Reserved*
138h
13Ah
13Ch
1C2h 0E8D
USB descriptor : idVendor
1C4h 7612
USB descrptor : idProduct
1C6h 0100
ASIC reserved
ASIC Reserved
1C8h 0111
ASIC reserved
ASIC reserved
1CAh 0000
ASIC reserved
ASIC reserved
1CCh E1A0
USB descriptor : Max Power
ASIC reserved
1CEh 0010
ASIC reserved
ASIC reserved
1D0h 0040
ASIC reserved
ASIC reserved
