Position Description see
page
A Webcam 13
B Stand 11
C Brightness control 13
D Source Select/Display off 13
E On/off switch (switches the PC on/off) / Power LED 18
G Headphone socket/speaker connections (line out) 15, 29
H Microphone input 14, 29
I Gigabit network (RJ-45, 10/100/1000 Mbit/s) 16
J
USB 3.0-ports
14 ,31
K
USB 2.0-ports
14, 31
L
HDMI OUT
16
M
HDMI IN
16
N Power supply (main connector & main power switch) 17
O Optical drive (CD/DVD/CDRW/DVDRW) 26
P 6-in-1 Card reader 28
Connections on the bottom Connections on the side
Connections on the back
Front
The shown connectors are for reference only.
Slight variations may occur.
Attention: Depending on the features of your PC model,
some connections may vary.
B
H
M
G
J
H
P
L
K
N
I
K
O
K
G
A
E
D
C
Product Diagram
