5.11. Connecting the Power Supply
Product Diagram position: N
When you have made all the connections, establish the power supply by
connecting the mains adapter supplied with the All-in-One PC.
Link the 3-pin mains adapter plug of the mains cable with the corresponding
socket to the mains adapter.
Plug the device plug of the mains adapters into the DC IN mains plug socket on
the back side of the All-In-One PCs.
Plug the mains plug on the mains cable into a 230 V ~ 50 Hz wall socket.
PLEASE NOTE!
The power supply unit has an On/Off switch. When the switch is Off (0) no
power is being consumed.
The socket must be close to the PC and easy to access.
Do not start your All-In-One PC yet!
First, read the following section to find out what you need to know in order to get
started.
