Meech HYPERION 233v4 User Manual

9
 Connect the 24V DC supply with 4 Pin M8 cable to the controller.
Electrical Installaon
WARNING
The 233v4 requires a grounded 24V DC supply. The 0V line must be
connected to ground. Failure to do so, will result in damage to the ioniser or
the 24V supply and will void the warranty.
A grounding post on the controller is provided for this purpose. Meech
recommend that, for certainty, the controller is grounded using this post, in
addion to using a grounded 24V DC supply.
