MAC/MTT-OPS-1
26 FEB 2019
SECTION 5
Performance
5-4
FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (41639 lit/11,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 2029 168436 0.065 0.105 1287 96543 0.114 0.183
U
5 440 5073 421090 0.026 0.042 3218 241356 0.046 0.073
S
10 880 10147 842180 0.013 0.021 6436 482713 0.023 0.037
15 1320 15220 1263270 0.009 0.014 9654 724069 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 611 15279 2.725 2.67 388 8916 4.670 4.65
T
8 134 1545 38629 1.078 1.07 980 22542 1.847 1.84
R
16 268 3090 77259 0.539 0.53 1960 45084 0.924 0.94
I
24 402 4636 115888 0.359 0.35 2940 67626 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (41639 lit/11,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 1558 121487 0.091 0.145 1232 80051 0.137 0.220
U
5 440 3894 303717 0.036 0.058 3079 200127 0.055 0.088
S
10 880 7788 607434 0.018 0.029 6158 400254 0.027 0.044
15 1320 11681 911150 0.012 0.019 9237 600382 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 469 11257 3.699 3.68 371 7418 5.613 5.59
T
8 134 1186 28461 1.463 1.47 938 18755 2.220 2.23
R
16 268 2372 56923 0.731 0.74 1876 37510 1.110 1.11
I
24 402 3558 85384 0.488 0.48 2813 56265 0.740 0.74
C
