Mega MAC - Page 50

MAC/MTT-OPS-1
26 FEB 2019
SECTION 5
Performance
5-5
FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (49,210 lit/13,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 2398 199061 0.065 0.105 1521 114096 0.114 0.183
U
5 440 5996 497652 0.026 0.042 3803 285239 0.046 0.073
S
10 880 11992 995304 0.013 0.021 7606 570479 0.023 0.037
15 1320 17987 1492956 0.009 0.014 11410 855718 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 722 18057 2.725 2.67 458 10537 4.670 4.65
T
8 134 1826 45653 1.078 1.07 1158 26641 1.847 1.84
R
16 268 3652 91306 0.539 0.53 2317 53281 0.924 0.94
I
24 402 5478 136959 0.359 0.35 3475 79922 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (49,210 lit/13,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 1841 143575 0.091 0.145 1455 94606 0.137 0.220
U
5 440 4602 358938 0.036 0.058 3639 236514 0.055 0.088
S
10 880 9204 717876 0.018 0.029 7277 473028 0.027 0.044
15 1320 13805 1076814 0.012 0.019 10916 709542 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 554 13304 3.699 3.68 438 8767 5.613 5.59
T
8 134 1402 33636 1.463 1.47 1108 22165 2.220 2.23
R
16 268 2803 67273 0.731 0.74 2217 44330 1.110 1.11
I
24 402 4205 100909 0.488 0.48 3325 66496 0.740 0.74
C
