Performance
5-6
FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (56,781 lit/15,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 2767 229686 0.065 0.105 1755 131649 0.114 0.183
U
5 440 6918 574214 0.026 0.042 4388 329122 0.046 0.073
S
10 880 13836 1148428 0.013 0.021 8777 658245 0.023 0.037
15 1320 20755 1722642 0.009 0.014 13165 987367 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 833 20835 2.725 2.67 529 12158 4.670 4.65
T
8 134 2107 52677 1.078 1.07 1336 30739 1.847 1.84
R
16 268 4214 105354 0.539 0.53 2673 61479 0.924 0.94
I
24 402 6321 158031 0.359 0.35 4009 92218 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (56,781 lit/15,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 2124 165664 0.091 0.145 1679 109160 0.137 0.220
U
5 440 5310 414159 0.036 0.058 4198 272901 0.055 0.088
S
10 880 10619 828319 0.018 0.029 8397 545802 0.027 0.044
15 1320 15929 1242478 0.012 0.019 12595 818702 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 640 15351 3.699 3.68 506 10116 5.613 5.59
T
8 134 1617 38811 1.463 1.47 1279 25575 2.220 2.23
R
16 268 3234 77623 0.731 0.74 2558 51151 1.110 1.11
I
24 402 4851 116434 0.488 0.48 3836 76726 0.740 0.74
C
