Mega MAC - Page 52

MAC/MTT-OPS-1
26 FEB 2019
SECTION 5
Performance
5-7
FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (75,708 lit/20,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 3690 306247 0.065 0.105 2340 175532 0.114 0.183
U
5 440 9224 765618 0.026 0.042 5851 438830 0.046 0.073
S
10 880 18449 1531237 0.013 0.021 11702 877660 0.023 0.037
15 1320 27673 2296855 0.009 0.014 17553 1316489 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1111 27780 2.725 2.67 705 16211 4.670 4.65
T
8 134 2809 70236 1.078 1.07 1782 40986 1.847 1.84
R
16 268 5619 140472 0.539 0.53 3564 81972 0.924 0.94
I
24 402 8428 210708 0.359 0.35 5346 122957 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (75,708 lit/20,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 2832 220885 0.091 0.145 2239 145547 0.137 0.220
U
5 440 7080 552212 0.036 0.058 5598 363868 0.055 0.088
S
10 880 14159 1104425 0.018 0.029 11196 727735 0.027 0.044
15 1320 21239 1656637 0.012 0.019 16794 1091603 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 853 20468 3.699 3.68 674 13487 5.613 5.59
T
8 134 2156 51749 1.463 1.47 1705 34100 2.220 2.23
R
16 268 4312 103497 0.731 0.74 3410 68201 1.110 1.11
I
24 402 6469 155246 0.488 0.48 5115 102301 0.740 0.74
C
