FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (113562 lit/30,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 5535 459371 0.065 0.105 3511 263298 0.114 0.183
U
5 440 13836 1148428 0.026 0.042 8777 658245 0.046 0.073
S
10 880 27673 2296855 0.021 17553 1316489 0.023 0.037
15 1320 41509 3445283 0.009 0.014 26330 1974734 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1667 41670 2.725 2.67 1057 24316 4.670 4.65
T
8 134 4214 105354 1.078 1.07 2673 61479 1.847 1.84
R
16 268 8428 210708 0.539 0.53 5346 122957 0.924 0.94
I
24 402 12642 316062 0.359 0.35 8019 184436 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (113562 lit/30,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 4248 331327 0.091 0.145 3359 218321 0.137 0.220
U
5 440 10619 828319 0.036 0.058 8397 545802 0.055 0.088
S
10 880 21239 1656637 0.018 0.029 16794 1091603 0.027 0.044
15 1320 31858 2484956 0.012 0.019 25191 1637405 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1279 30702 3.699 3.68 1012 20231 5.613 5.59
T
8 134 3234 77623 1.463 1.47 2558 51151 2.220 2.23
R
16 268 6469 155246 0.731 0.74 5115 102301 1.110 1.11
I
24 402 9703 232868 0.488 0.48 7673 153452 0.740 0.74
C
