Mega MAC - Page 54

MAC/MTT-OPS-1
26 FEB 2019
SECTION 5
Performance
5-9
FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (132489 lit/35,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 6457 535933 0.065 0.105 4096 307181 0.114 0.183
U
5 440 16143 1339832 0.026 0.042 10239 767952 0.046 0.073
S
10 880 32285 2679665 0.013 0.021 20479 1535904 0.023 0.037
15 1320 48428 4019497 0.009 0.014 30718 2303856 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1945 48615 2.725 2.67 1233 28369 4.670 4.65
T
8 134 4917 122913 1.078 1.07 3118 71725 1.847 1.84
R
16 268 9833 245826 0.539 0.53 6237 143450 0.924 0.94
I
24 402 14750 368738 0.359 0.35 9355 215175 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (132489 lit/35,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 4956 386549 0.091 0.145 3919 254707 0.137 0.220
U
5 440 12389 966372 0.036 0.058 9796 636768 0.055 0.088
S
10 880 24779 1932743 0.018 0.029 19593 1273537 0.027 0.044
15 1320 37168 2899115 0.012 0.019 29389 1910305 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1492 35818 3.699 3.68 1180 23603 5.613 5.59
T
8 134 3773 90560 1.463 1.47 2984 59676 2.220 2.23
R
16 268 7547 181120 0.731 0.74 5968 119351 1.110 1.11
I
24 402 11320 271680 0.488 0.48 8951 179027 0.740 0.74
