FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (158,988 lit/42,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 7748 643119 0.065 0.105 4915 368617 0.114 0.183
U
5 440 19371 1607799 0.026 0.042 12287 921543 0.046 0.073
S
10 880 38742 3215597 0.013 0.021 24574 1843085 0.023 0.037
15 1320 58113 4823396 0.009 0.014 36862 2764628 0.015 0.024
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 2334 58338 2.725 2.67 1480 34043 4.670 4.65
T
8 134 5900 147496 1.078 1.07 3742 86071 1.847 1.84
R
16 268 11800 294993 0.539 0.53 7484 172142 0.924 0.94
I
24 402 17700 442489 0.359 0.35 11227 258212 0.616 0.61
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (158,988 lit/42,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176 5947 463858 0.091 0.145 4702 305649 0.137 0.220
U
5 440 14867 1159646 0.036 0.058 11756 764122 0.055 0.088
S
10 880 29735 2319292 0.018 0.029 23511 1528244 0.027 0.044
15 1320 44602 3478938 0.012 0.019 35267 2292366 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53 1791 42983 3.699 3.68 1416 28324 5.613 5.59
T
8 134 4528 108673 1.463 1.47 3581 71611 2.220 2.23
R
16 268 9056 217346 0.731 0.74 7161 143223 1.110 1.11
I
24 402 13584 326018 0.488 0.48 10742 214834 0.740 0.74
C
