FINE SPRAY (1/4” SLOT HEIGHT) & FULL FAN (196,841 lit/52,000 gal TANK)
2 SPRAY HEADS (FLOW 3611 lpm/954 gpm) 4 SPRAY HEADS (FLOW 5693 lpm/1504 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176
9339 775118 0.067 0.108 8320 624000 0.083 0.134
U
5 440
23347 1937796 0.027 0.043 20800 1560000 0.033 0.053
S
10 880
46694 3875592 0.013 0.022 41600 3120000 0.017 0.027
15 1320
70041 5813388 0.009 0.014 62400 4680000 0.011 0.018
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53
2755 68877 2.800 2.67 2455 56454 3.416 3.42
T
8 134
6966 174143 1.107 1.07 6206 142734 1.351 1.35
R
16 268
13931 348285 0.554 0.53 12412 285467 0.676 0.68
I
24 402
20897 522428 0.369 0.35 18617 428201 0.450 0.45
C
HEAVY SPRAY (3/8” SLOT HEIGHT) & FULL FAN (196,841 lit/52,000 gal TANK)
2 SPRAY HEADS (FLOW 4705 lpm/1243 gpm) 4 SPRAY HEADS (FLOW 5950 lpm/1572 gpm)
SPRAY
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
MAX
DISTANCE
TOTAL
COVERAGE
DISPERSAL
WATER
LAYER
SPEED
MPH FPM (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT) (FT) (SQ FT) (GAL/SQ FT) (IN/SQ FT)
2 176
7363 574301 0.091 0.145 5822 378422 0.137 0.220
U
5 440
18407 1435752 0.036 0.058 14555 946056 0.055 0.088
S
10 880
36814 2871504 0.018 0.029 29109 1892112 0.027 0.044
15 1320
55221 4307257 0.012 0.019 43664 2838168 0.018 0.029
M
KPM MPM (METER) (M SQ) (L/M SQ) (MM) (METERS) (M SQ) (M/M SQ) (MM)
E
3 53
2172 52135 3.699 3.68 1718 34355 5.613 5.61
T
8 134
5492 131812 1.463 1.47 4343 86859 2.220 2.22
R
16 268
10984 263625 0.731 0.74 8686 173719 1.110 1.11
I
24 402
16477 395437 0.488 0.48 13029 260578 0.740 0.74
C
