Mega MAC - Abbreviations and Symbology

MAC/MTT-OPS-1
26 FEB 2019
SECTION 1
Definitions and Abbreviations
1-5
Confined Space (12)
This safety label is located near the water tank
access and fill ports.
Do not enter confined spaces without following
established site specific procedures. Failure to
follow proper safety procedures will result in
serious injury or death.
ABBREVIATIONS
BFV Butterfly Valve
cc Cubic Centimeters
CCW Counter Clockwise
CW Clockwise
fl. oz. Fluid Ounce
FT Feet
FPM Feet Per Minute
GPM Gallons Per Minute
IN/SQ FT Inches per Square Feet
Kg kilograms
Kpa Kilopascals
l liters
lpm Liters per minute
LT Left as viewed from the operator’s
position facing forward
m meters
MAC MEGA Articulated Conversion
MPH Miles Per Hour
MTT Mega Truck Tank
Nm Newton meters of torque
psi pounds per square inch
RPM Revolutions Per Minute
RT Right as viewed from the operator’s
SQ FT Square Feet
VDC Volts, Direct Current
SYMBOLOGY
IN-CAB SUPPLEMENTS
Checklists
A pocket size Operator’s Checklist of all procedures is
contained in the Appendix for use in the vehicle cab.
Place a copy of the Appendix Operator’s Checklist
within the cab for daily use.
Instructional Decals
Instructional decals are included at the beginning of
the Appendix. These decals may be cut out and
placed in the cab wherever is most convenient for
the operator.
Symbol Name
POWER
PUMP
INTMN
T/
AUTO2
LIGHTS
F1
F2
PAUSE
WATER
LEVEL
AUTO
AUX 1
AUX 2
HOSE
LT VSS
Symbol Name
DRAIN
DUMP
BAR
RT VSS
LT REAR
LT CTR
RT CTR
RT
REAR
Symbol Name
