There is also an audible alarm in the instrument body and LEDs on the Dual-
point Lead set to indicate circuit and measurement status. The following chart
details the conditions under which the audible alarm and LEDs activate. The
circuit and measurement status is also displayed on the LCD.
Red No Circuit
Yellow- Blinking Circuit found, not measuring
Yellow- Solid Circuit found, measuring
Green Measuring complete, Okay to remove probes.
LED Status Indicators
No connection
(( ))
Connection detected
Measuring
Measurement complete
