Megger BITE 3 User Manual

M
AVTMBITE 3 Rev 8 April 2014
18
Step Two: Turning on the BITE 3 and Connecting the Lead Set.
The BITE 3 is a PC-based instrument running Windows CE. It will take about
30 seconds to boot up and be ready to take measurements.
1. Turn on the BITE 3 by pressing the on/off (O | I) button. The back light
should stay lit.
2. Connect the lead set and, if used, the CT to the BITE 3.
3. a) Configure a new site and string.
Configure I Strings I New
Enter New String Information
Site:
String name:
Baseline:
1.00
mΩ
Warning: 15
▲
▼
%
Fail: 30
▲
▼
%
Change: 20
▲
▼
%
Deviation: 0
▲
▼
%
-or-
b) Select a site/string to be tested (See Chapter 3 for the flowchart of the
menus.)
Measure I New Test
Select a String
Site:
I
▲
▼
String:
▲
▼
Measure I New Test
Select and Continue : a String
Close
Site:
I
▲
▼
String:
▲
▼
