AVTMBITE 3 Rev 8 April 2014
31
APPENDIX A - Technical Specifications
Electrical
Impedance Range and Resolution
0.05 to 1.000 m 1 μ resolution
1 to 10.00 m 10 μ resolution
10 to 100.0 m 0.1 m resolution
Voltage Range and Resolution
1 to 15 VDC across probes
1 to 8.0 V dc 1 mV resolution
8.0 to 15 VDC 10 mV resolution
Current Range and Resolution
Current: 0.5 – 9.99 A ac/dc 0.01 A resolution
10.0 – 99.9 A ac/dc 0.1 A resolution
Accuracy
dc voltage: (1% rdg +1 lsd)
ac impedance: (5% of rdg +1 lsd)
current: (5% rdg + 0.5 A)
Precision Better than 0.5% one sigma
Source Output Current: ½ A rms
Display: 1/4 VGA LCD
Display Size: 2.83” x 2.95” (72mm x 57mm)
Settling Time per Reading: approximately 6 to 8 seconds
Battery Pack: 2-3 hours continuous
4.8V dc, 7000 mAh, quick charge NiMH battery pack
