Megger DET2/2 - Features and Controls

6
Features and Controls
To electrode under test
(Potential connection)
To electrode under test
(Current connection)
Charger socket
External 12 V d.c.
supply Terminals
Display contrast
adjustment
To Potential test spike
To Current test spike
On / Off Test Button
(Rotate clockwise
to lock)
3
1
⁄2 digit L.C.D.
Test control
switches
