The Catalog No. 247100 is a 100 Ampere Test System
composed of a Catalog No. 247000 Measuring Module,
and a Cat. No. 247120 100-amp power supply. The
Catalog No. 24701 is also a 100 ampere test system.
The ohmmeter has four terminals for a Kelvin connection
to the sample under test, and it is recommended that
Biddle test leads shown in Bulletin 24-1 be used with this
instrument.
Panel features include a two-position on-off switch that
allows continuous or momentary operation, and on the
rechargeable battery models a meter to indicate relative
state of charge of the internal batteries.
A prop is provided to keep the lid in a partly open position
so that it can be used as a sunshade when reading the
digital display in bright sunlight.
The Catalog No. 247002 is similar to Catalog No. 247001
except that it has an extra 600 µΩ range.
