AVTM24-1J REV A April 2006
43
Section C
DESCRIPTION & SPECIFICATIONS
DESCRIPTION
The components of the measuring system are as follows:
1. Compact DLRO measuring module with rechargeable
battery in molded case.
2. Battery Charger in similar molded case.
3. 100-Ampere DC current source having four test
connection terminals used for the 100-Amp range.
All the above are parts of Catalog No. 247100. In addition,
four test leads are required.
Complete information on the basic measuring module and
charger is given in Part I.
Specifications covering the adaptation of this basic
instrument for the 600 micro-ohm range as well as
specifications covering the 100-Ampere source and range
module are as follows:
