M
AVTM24-1J REV A April 2006
8
Interference
Effects:
Error in item under test caused by
line- frequency current of 0.1X test
current: ±l lsd
Error caused by 5-gauss line-
frequency
magnetic field: ±2 lsd
Error caused by connection to
ground or voltage to ground
(assuming battery operation): None
Input
Protection:
One volt peak may be applied
between any two of the Rx terminals.
Effect of
Inductive Test
Item:
None except time constant delay. No
damage caused by inductive kick, but
see precautions in Section H.
Temperature
Range:
Operating: 0-50°C
(line supply, 0-40°C)
Storage: -40°C to + 60°C
Display: Red LED, 4 digits 0.5” high, decimal
point, and negative (-) sign. Upper
right hand segments of digits flash on
overrange input
