Description & Specifications
AVTM24-1J REV A April 2006
45
Specifications
Measurement Data
LIMIT OF ERROR
RANGE
TEST
CURRENT
AMPERES
RESOLUTION
1 year
15-35°C
1 year
0-50°C
000.0 - 600.0 mO 100 0.1 µO ½ % Rdg + 2 lsd* 1 % Rdg + 2 lsd*
*(Least Significant Digit)
Response
Time:
(After ON—OFF switch is closed):
Ten seconds to final reading,
maximum.
Duty Cycle
and Ambient
Temperature:
Ambient 50C: Continuous
100-Ampere Current Source and Range Module:
Power Input: 120V, 60 Hz, 10A
(Cat. No. 247100)
230V, 50/60 Hz, 10A
(Cat. No. 247100-47)
Output: 1 Volt, 100A dc
Weight: 20- ½ pounds (9.3 kg)
