M
AVTM24-1J REV A April 2006
48
2. Test Current Adjustment
Test current indicated on the ammeter should be 100A. If
adjustment is necessary, it can be made by the current
adjustment knob. Fluctuations in test current may be
caused by line voltage swings or poor connections.
3. Test Time
Reading will settle in ten seconds or less. Shut off power
(Switch on supply to OFF) as soon as reading is complete.
CAUTION: BEWARE OF BURNS!
The current leads become warm after a few minutes of
operation. Poor connections to the item under test or in
the item under test itself if it is physically small or poorly
cooled may result in a very hot item.
