Insulation
Range: 100 kΩ to 20 GΩ (also 0 Ω and ∞)
Test Voltages (d.c.): 500 V, 1000 V, 2500 V & 5000 V
Test Voltage Accuracy: ±5% of nominal test voltages on 20 MΩ load
Test Voltage Stability: <±1% (180 r.p.m. to 240 r.p.m. MJ15)
Insulation Accuracy (at 0 - 30˚C): ±2,5% of scale
Short Circuit Current: 1,5 mA ± 0,5 mA
Maximum capacitance of load: 5 µF
Interference Rejection: 1 mA rms at 50 to 60 Hz
Discharge Resistor: <500 kΩ
Voltage
Range: 0 to 600 V a.c. indication of d.c.
Accuracy: ± 2,5% f.s.d.(with rotary switch in the V position) ± d.c. unspecified
General
Overload rating: 720 V a.c. or d.c.
Scale Length: 72 mm (96˚)
Power Supply: BM15 8 x LR6 (AAalkaline or rechargeable) cells
MJ15 Low voltage brushless Generator or 8 x LR6 (AA alkaline) cell battery
Battery life: Typically 2000 five second tests at 5 kV on 100 MΩ load
Battery Indicator: Loaded battery test
Specification
