AVTMMTO210 Rev 7 Sept 2013
65
9
Specifications
INPUT
120/230 V, 50/60 Hz, 750 VA
OUTPUT
User Selectable Current Ranges:
up to 10 mA
up to 100 mA
up to 1 A
up to 10 A
Test Voltage:
up to 50 Vdc
RESISTANCE MEASUREMENT/DISPLAY
Resistance:
@ 10A 1 μΩ to 2Ω res. 0.1 uΩ
@ 1.0A 10 μΩ to 20Ω res. 1.0 uΩ
@ 100mA 100 μΩ to 200Ω res 10 uΩ
@ 10mA 1.0 mΩ to 2000Ω res 0.1 mΩ
Accuracy:
±0.25% reading, ±0.25% full scale
Resolution:
4 digits
Displays
Two 1’’ high, 6 character, 7-segment, LCDs
One 0.71” high, 6 character, 7-segment, LCD
PRINTER
Via RS-232 port
USER INTERFACE
B&W numeric displays, keypad
COMPUTER INTERFACE
(for downloading results)
Via RS-232 port
INTERNAL DATA STORAGE
Up to 2,000 data sets (256Kbytes)
ENVIRONMENTAL
Operating:
14° F to 122° F (-10° C to 50° C)
Storage:
5° F to 158° F (-15° C to +70° C)
Relative Humidity:
0-90% non-condensing
DIMENSIONS
8.5 H x 21.5 W x 13 D
(216 H x 546 W x 330 D mm)
WEIGHT
Net 29 lb (13.1 kg)
