OTS80PB and OTS60PB OTS100AF, OTS80AF and OTS60AF
28
Manage test standards
9. Manage test standards
9.1. Custom tests
Custom tests are tests that can be defined by a user by giving the user control over the range of parameters set in a
test. Three custom tests and 6 withstand tests have been pre-programmed for user definition;
 Custom (5) – this test contains 5 successive breakdown tests
 Custom (6) – this test contains 6 successive breakdown tests
 Custom (10) – this test contains 10 successive breakdown tests
9.2. Withstand tests
Withstand tests are defined tests that can be modified that meeting standards.
 Withstand A
 Withstand B
 BS 5730a AD 30 kV
 BS 5730a AD 40 kV
 BS 5730a BCEF 22 kV
 BS 5730a BCEF 30 kV
9.3. Editing test parameters
Navigate to the Tools top level screen as illustrated below.
Select, “Manage Test Standards” by pressing the OK button.
To edit custom tests select “Edit Custom Test Parameters” and
press the OK button.
