Megger PAT100 Series User Manual

www.megger.com
34
Specification
ENVIRONMENTAL CONDITION:
Operating ambient 20°C
Humidity Nominal humidity
CONTINUITY TEST
Test voltage Compliance Voltage: +4 V dc
-0% / +30% (open circuit)
Test current Bi-directional +200 mA
-0% +50 mA (into 2 Ω load)
Continuity accuracy Resistance: ± 5% ± 3 digits (0 to 19.99 Ω)
Resistance resolution 10 mΩ
Display range 0.01 to 19.99Ω
Continuity test nulling up to 9.99 Ω
Test time User selectable from 2 sec to 20 sec or selected
during test to 180 sec
INSULATION TEST
Insulation test 250 V dc –0 % /+25 % open circuit
500 V dc –0 % /+25 % open circuit
≥ 500V –0% dc across 0.5 MΩ load
Short circuit/charge current < 2 mA dc
Insulation accuracy ±3% ±10 digits (0 to 19.99 MΩ)
Resolution 0.01 MΩ
Display range 0.10 MΩ to 99.99 MΩ
Test duration User selectable from 2 sec to 20 sec or selected
during test to 180sec
SUBSTITUTE LEAKAGE TEST
Leakage current Accuracy ± 5% ± 3 digits
Test frequency Nominal mains frequency 50Hz
Test voltage < 50 V ac
Leakage Current Resolution 0.01 mA
Display range 0.10 to 19.99 mA
Test duration User selectable from 2 sec to 5 seconds
Reading corrected to 230V ac.
DIFFERENTIAL LEAKAGE CURRENT
Test voltage Nominal supply voltage 230 V ac
Test frequency Nominal mains frequency 50 Hz
Test accuracy ±5% ±3d ±3uA/A
Resolution 0.01 mA
Display range 0.10 to 19.99 mA
Test duration User selectable from 2 sec to 5 seconds
TOUCH CURRENT TEST
Test voltage Nominal mains 230 V ac
Test frequency Nominal mains 50 Hz
Test accuracy ± 5% ± 3 digits
Resolution 0.01 mA
Display range 0.10 to 3.99 mA
Test duration User selectable from 2 sec to 5 sec
SELV DEVICE TEST
Test voltage 0 to 300 V ac
Measurement accuracy ± 3% ± 3 digits
Resolution 0.1 V ac
Display range 0.1 to 300 V ac
EXTENSION LEAD TEST
Test includes Insulation and Bond tests.
Test voltage 5 V
Polarity Lead OK
Live neutral shorted
Live neutral reversed
Live/neutral open circuit
PORTABLE RCD TEST
Test voltage Nominal mains 230 V
Test frequency 50 Hz
Test current accuracy +2% to +8% (1 x I, 5 x I)
Trip time accuracy ±1% ± 1 ms
Trip time resolution 0.01 ms
Display range 0 to 200 ms (1 x I)
0 to 40 ms (5 x I)

Megger PAT100 Series Specifications

General

Brand	Megger
Model	PAT100 Series
Category	Test Equipment
Language	English
