10
Carry strap fitting and removal
Fitting the carry strap:
Removing carry strap:
Connect the P1 test lead to socket P1 on the
Pat100 and the probe to exposed metalwork
Ensure the probe is NOT connected to a 230V
source.
Connect the P1 test lead to different conductive
points on the equipment under test during the
measurement
Connect both the P1 and P2 test leads to the
circuit to be measured
Ensure equipment under test is switched ON
