www.megger.com
7
Instrument Layout PAT120 Instrument Layout PAT150
Display information PAT120 Display information PAT150
Test results
Test
information
Information/
Warnings
Overall PASS/FAIL
Test
information
Information/
Warnings
Overall PASS/FAIL
Test results
Neck strap
slot
Test groups
Power ON – Hold for >0.5s Backlight
Main test
socket
Power ON –
Hold for >0.5s
BacklightQuick test Setup
Neck strap
slot
Test groups
Main test
socket
