20
motor model
P03.03
Rated
current of
motor
Rated
current
0.1~999.9A 0.1A
Dependin
g on
model
√ √ ×
P03.04
Rated
frequency
of motor
Rated
frequency
1.00~3000.0Hz 0.01Hz
Dependin
g on
model
√ √ ×
P03.05
Rated
rotating
speed of
motor
Rated
rotating
speed
0~60000rpm 1rpm 1440rpm √ √ ×
P03.06
Power
factor of
motor
Power factor
0.001~1.000
It shall be used when calculating
the motor parameters with the
nameplates
0.001
Dependin
g on
model
√ √ ×
P03.07
Stator
resistance
of motor
Stator
resistance
R1
0.000~65.000 0.001
Dependin
g on
model
√ √ ×
P03.08
Leakage
inductanc
e of motor
Leakage
inductance X
0.0~2000.0 0.1
Dependin
g on
model
√ √ ×
P03.09
Rotator
resistance
of motor
Rotator
resistance of
motor
0.000~65.000 0.001
Dependin
g on
model
√ √ ×
P03.10
Mutual
inductanc
e of motor
Mutual
inductance of
motor
0.0~2000.0 0.1
Dependin
g on
model
√ √ ×
P03.11
No-load
current (I
0
)
of motor
No-load
current (I
0
)
0.1~999.9A 0.1A
Dependin
g on
model
√ √ ×
P03.12
Overload
protection
factor of
motor
Overload
protection
factor of
motor
20.0%~110.0%
0.1% 100.0% √ √ ×
P03.25
Paramete
r
auto-tunin
g
Parameter
auto-tuning
0: Disabled
1: Enabled (motor in static status)
2: Enabled (motor in rotate status)
1 0 √ √ ×
Group P04: Encoder parameters
P04.01
Number of
pulses per
revolution
of local
PG
Number of
pulses per
revolution of
PG
1~10000 1 1024 √ √ ○
P04.02
Rotation
direction
of local
PG
PG rotation
direction
0: A before B
1: B before A
1 0 √ √ ×
