5.3 Lifting application(closed loop/open loop vector) typical wiring
Uplink
Downlink
Multi-speed input 1
Multi-speed input 2
Multi-speed input 3
Brake detection input
Fault reset input
/Voltage/current signal
MV600L
PE
AI3-
AI3+
GND
AI1/ AI2
X1
X2
X3
X4
X5
X6
X7
X8
-10
+10
COM
P24
PLC
R/L1
S/L2
T/L3
+DC
B2 -DC
U
V
W
PE
12C
COM
PE
GND
AO1
Y1
Y2
TB
TA
TC
BRA
BRC
M
PG
COM
RS485+
RS485-
P/B1
AI1
AI2
0-10V
AO1
AO2
0-20mA
-10V-10V
0-20mA
P24
AO2
B-
B+
A-
A+
Fault relay
Brake control relay
Three Phase
380V
50/60Hz
Braking resistor
DCL DC reactor
(External, optional part)
Standard RS485 Modbus
PE
Fig. 5-3 Lifting application typical wiring (open loop:no encoder connection)
