Megmeet MV600L Series User Manual

36
P97.03
Overload
protection
setting for
motor
Overload
protection
setting
Unit place of LED: Overload
compensation mode
0: No action
1: Common motor (with
low-speed compensation)
2: Variable-frequency motor
(without low-speed
compensation)
Tens place of LED: Overload
pre-alarm detection selection
0: Always detect
1: Detect only at constant speed
Hundreds place of LED: Overload
pre-alarm action selection
0: Alarm and keep running
1: Activate protection and coast to
stop
Thousands place of LED:
Overload detection level selection
0: Relative to rated current of the
motor (Er.oL1)
1: Relative to rated current of the
drive (Er.oL2)
1 0001 × √ ×
P97.04
Overload
pre-alarm
detection
level
Overload
detection
level
20.0%~200.0% 0.1% 130.0% × √ ○
P97.05
Overload
pre-alarm
detection
time
Overload
detection
time
0.0~60.0s 0.1s 5.0s × √ ○
P97.06
Motor
over-temp
erature
protection
point
Motor
over-temper
ature
protection
point
0.00~10.00V 0.01 0 × √ ○
P97.07
Over-volta
ge stall
selection
Over-voltage
stall
selection
0: Disabled (when the braking
resistor is installed)
1: Enabled
1 1 × √ ×
P97.08
Over-volta
ge point at
stall
Over-voltage
point at stall
120.0%~150.0%Udce 0.1%
140.0％
× √ ×
P97.09
Auto
current
limiting
action
selection
Auto current
limiting
action
0: Disabled at constant speed
1: Enabled at constant speed
Note: Always enabled for
acceleration/deceleration
1 1 × √ ×
P97.10
Auto Current
20.0%~200.0%Ie 0.1% 150.0% × √ ×
