MeiTrack T711L - Product Specifications; Main Device and Accessories

MEITRACK T711L GPS Vehicle Tracker User Guide
Copyright © Meitrack Group 2021. All rights reserved. - 6 -
 A-GPS
 Idling alert
 Harsh acceleration alert
 Harsh braking alert
 Harsh cornering alert
 Vehicle maintenance reminding
 Online Parameter Editor (MS03 platform)
 Support online OTA updates
3.2 Product Specifications
Item Specifications
Dimension 75 mm x 44 mm x 17 mm
Weight 77g
I/O power cable length 50 cm
Power supply DC 11.4–90 V/1.5 A
Power consumption Current in standby mode: 65 mA
Operating temperature -35°C to 80°C (for the device without a battery)
-20°C to 60°C (for the device with a normal temperature resistant battery)
Operating humidity 5%–95%
LED indicator Green LED indicator showing the GSM signal
Blue LED indicator showing the GPS signal
Button/Switch 1 upgrade button (used to manually upgrade the firmware)
1 power button
Memory 8 MB flash
Sensor 3-axis accelerometer
Frequency band T711L-E:
LTE FDD: B1/B3/B5/B7/B8/B20/B28
LTE TDD: B38/B40/B41
GSM: 850/900/1800/1900
Bluetooth 2.4G Internal Bluetooth module, compatible with Bluetooth 5.0 GHz
GPS sensitivity -165 dB
GNSS Dual-mode positioning (GPS/BeiDou/GLONASS)
Positioning accuracy 2.5 meters
I/O port 1 positive input by default (ACC)
1 analog detection input (0–30 V)
1 open collector
1 1-Wire port
1 debug interface (Micro USB)
4 Main Device and Accessories
Standard accessories:
