MEITRACK T711L GPS Vehicle Tracker User Guide
Copyright © Meitrack Group 2021. All rights reserved. - 7 -
 T711L vehicle tracker (with a cable of 50 cm in length)
 Normal temperature resistant battery (200 mAh)
 L wrench
 Hexagon screw
 CD download card
Optional accessories:
Optional Accessory Description
USB cable Standard Android cable
Relay (12 V/24 V) It is connected to output 1 or the 1-Wire port (green cable), which needs to be
set to output 2.
Buzzer It is connected to output 1 or the 1-Wire port (green cable), which needs to be
set to output 2.
A52 digital temperature sensor It is connected to the 1-Wire port (green cable). An external 5 V power supply
is required to supply power, or it is connected to A61 sensor box for more
functions.
iButton reader It is connected to the 1-Wire port (green cable).
A53 fuel level sensor (analog input
voltage)
It is connected to analog input 1 (blue cable).
Bluetooth temperature and
humidity sensor
Check temperature (-20°C to 55°C) and humidity (0% to 100% RH).
(A maximum of four Bluetooth temperature and hu
midity sensors are
supported.)
Bluetooth beacon Detect the location of the tracker or Bluetooth beacon. (A maximum of 16
Bluetooth beacons are supported.)
High temperature resistant
battery (200 mAh)
Operating temperature: -5°C to 75°C
5 Product Appearance
