MeiTrack VT300 - VT300 Technical Characteristics; Getting Started with VT300; Hardware and Accessories Included

- 4 -
3 VT300 Characteristics
Items
Specification
Power Supply
+9V - +36V / 1.5A
Backup Battery
850mAh
Normal power consumption
85mA/h
Dimension
115mm x 60mm x 21mm
Installation Dimension
115mm x 79mm x 21mm
Weight
140g
Operating temperature
-20° to 55° C
Humidity
5% to 95% Non-condensing
Frequency
GSM 900/1800/1900Mhz or GSM 850/900/1800/1900Mhz (optional)
GPS Chipset
latest GPS SIRF-Star III chipset
GPS Sensitivity
-159Db
GPS Frequency
L1, 1575.42 MHz
C/A Code
1.023 MHz chip rate
Channels
20 channel all-in-view tracking
Position Accuracy
10 meters, 2D RMS
Velocity Accuracy
0.1 m/s
Time Accuracy
1 us synchronized to GPS time
Default datum
WGS-84
Reacquisition
0.1 sec., average
Hot start
1 sec., average
Warm start
38 sec., average
Cold start
42 sec., average
Altitude Limit
18,000 meters (60,000 feet) max.
Velocity Limit
515 meters/second (1000 knots) max.
LED
1 LED light to show working status.
Button
One SOS button
Interface
One input and one output
4. Getting Started
This section will describe how to set up your VT300.
4.1 Hardware and Accessories
VT300 is supplied in a box which includes:
