Delivery, transport and setting up
3.6.4 Adjusting the doors (only for model sizes 400/750/1060)
For model sizes 400/750/1060, it is possible to adjust doors that warp due to the floor condi-
tions. In order to do so, every door has two adjuster screws at the top and at the bottom (Fig.
10).
First, adjust the door at the top and then, if further adjustment is necessary, at the bottom
as well.
1. Open the door.
2. Undo the screws.
3. Adjust the door.
4. Tighten the screws again.
5. Check door alignment.
6. If necessary, readjust.
Fig. 10 Door adjustment screws
