Service IPP 200-500/HPP 108 | 10/2008
If the fault is not down to the water supply, continue as follows:
Remove the top panel (see page 11). In the control unit that 1.
is now accessible you will find the following components for
regulating humidity:
1
2 3
4
Fig. 25: Components of humidity regulation in the control unit
Pump1
Control module2
Fuse for control module3
Power supply unit4
Check that all plugs are connected.2.
Check that the fuse for the control module (3) is OK. If not: 3.
replace the fuse.
Check that the pump is running (1). If not: Replace the pump 4.
(see page 36).
If the error has still not been been found, then the steam 5.
generator at the back of the appliance is faulty. In this case it
must be replaced (see next chapter).
