41
Service IPP 200-500/HPP 108 | 10/2008
1
2
3
4
5
Fig. 31: Replacing the humidity sensor
Humidity sensor in the insulation material on the rear panel of the appliance1
Connection cable in the control unit 2
Allen set screw3
Undo the Allen set screw with the 1.5 mm Allen key through the opening in 4
the insulation material on the side wall
Pull the humidity sensor out and upwards through the opening in the floor 5
of the control unit
Spare part Spare part number
Humidity sensor E05249
