3. Loosen, but do not remove the screw that secures the cowl latch to the
driveshaft housing covers.
63041
4. Loosen the seven screws that secure the starboard driveshaft cover, and
remove the cover.
63039
Installation
Install the starboard cover after the shift and throttle cables are installed.
1. Position the starboard cover on the driveshaft housing and secure it with
seven screws.
2. Tighten the seven starboard‑side screws and the cowl latch screw to the
specified torque.
Description
Nm lb‑in. lb‑ft
Driveshaft housing cover and cowl
latch screws (11)
6 53 –
ENGINE INSTALLATION
eng 115
