GENERAL INFORMATION
32
Specifications
MODEL 9.9 MH 9.9 EH
Overall lengh 869 mm (34.2 in.)
Overall width 345 mm (13.6 in.)
Overall height
S=1067 mm (42.0 in.), L=1194 mm (47.0 in.),
UL=1321 mm (52.0 in.)
Transom height
S=435 mm 17.1 in.), L=562 mm (22.1 in.),
UL=689 mm (52.0 in.)
Weight
9.9 MH=41.0 kg (90.3 lb), 42.0 kg (92.6 lb), 43.0 kg
(94.8 lb)
9.9 EH=44.0 kg (97.0 lb), 45.0 kg (99.2 lb), 46.0 kg
(101.4 lb)
Output 7.3 kW
Max operating range 4500–5300 rpm
Number of cylinders 2
Displacement 247 mL
Bore x stroke 55 x 52 mm (2.1 x 2.0 in.)
Exhaust system Through hub exhaust
Lubrication system Engine oil mixed gasoline
Cooling system Thermostat controlled
Starting system Manual Electric w/manual backup
Ignition Flywheel magneto CDI
Spark plugs
NGK B7HS‑10/BR7HS‑10
or CHAMPION L82C/RL82C (gap 1.0 mm/0.039 in.)
Trim system Manual, 6 positions
Engine oil mixing ratio
Mercury/Quicksilver 2‑stroke engine oil 1:
Unleaded gasoline 50
Gear oil
Mercury/Quicksilver gear oil API GL5,
SAE #80–90, approximately 370 mL
Fuel tank capacity 25 L
Gear reduction ratio 13:24
