Tube Ref
No.
Description Where Used Part No.
Extreme Grease Propeller shaft 8M0071842
95
2-4-C with PTFE Propeller shaft 92-802859A 1
7. Install the front thrust washer, propeller, rear thrust washer, and propeller
nut onto the shaft.
8. Place a block of wood between the gearcase and propeller to prevent
rotation and tighten the propeller nut. Secure the propeller nut to the shaft
with the cotter pin.
a - Cotter pin
b - Propeller nut
c - Rear thrust washer
d - Propeller
e - Front thrust washer
Fuse Replacement ‑ Electric Start Models
IMPORTANT: Always carry spare 20‑amp fuses.
The electric starting circuit is protected from overload by a 20‑amp fuse. If the
fuse is blown, try to locate and correct the cause of the overload. If the cause is
not found, the fuse may blow again.
a - Spare fuse
b - Circuit protecting fuse
MAINTENANCE
86 eng
