3. Set the spark plug gap to specification.
Spark Plug
Spark plug gap 0.9 mm (0.035 in.)
4. Before installing spark plug, clean off any dirt on the spark plug seat.
Install plug finger‑tight, and then tighten 1/4 turn or torque to
specifications.
Description
Nm lb‑in. lb‑ft
Spark plug 27 – 20
Timing Belt Inspection
Inspect the timing belt and have it replaced by an authorized dealer if any of the
following conditions are found.
• Cracks in the back of the belt or in the base of the belt teeth.
• Excessive wear at the roots of the cogs.
• Rubber portion swollen by oil.
• Belt surfaces roughened.
• Signs of wear on edges or outer surfaces of belt.
Changing Engine Oil
ENGINE OIL CAPACITY
Engine oil capacity is approximately 800 ml (27 fl oz).
MAINTENANCE
88 eng
