Mercury 200 Operation And Maintenance Manual

FEATURES AND CONTROLS
30
ob00665
AUXILIARY TILT SWITCH
The auxiliary tilt switch can be used to tilt the outboard up or down using the power trim system.
a
ob00666
a - Auxiliary tilt switch
SHALLOW WATER OPERATION
When operating your boat in shallow water, you can tilt the outboard beyond the maximum trim range to prevent
hitting bottom.
1. Reduce engine speed below 2000 RPM.
2. Tilt outboard up. Make sure all the water intake holes stay submerged at all times.
3. Operate the engine at slow speed only. If engine speed exceeds 2000 RPM, the outboard will automatically
return down to the maximum trim range.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
