Mercury 200 Operation And Maintenance Manual

FUEL AND OIL
24
Filling Fuel Tank
!
WARNING
Avoid serious injury or death from a gasoline fire or explosion. Always stop the engine and do not smoke or
allow open flames or sparks in the area while filling fuel tanks.
Fill fuel tanks outdoors away from heat, sparks, and open flames.
Remove portable fuel tanks from boat to refill them.
Always stop engine before refilling tanks.
Do not completely fill the fuel tanks. Leave approximately 10% of the tank volume unfilled. Fuel will expand in
volume as its temperature rises and can leak under pressure if the tank is completely filled.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
