GENERAL INFORMATION
18
Component Identification
a
b
c
d
e
f
g
h
i
j
ob01522
a - Top cowl
b - Bottom cowl
c - Water pump indicator hole
d - Driveshaft housing
e - Anti‑ventilation plate
f - Anode plate
g - Auxiliary tilt switch
h - Transom brackets
i - Gearcase
j - Cooling water intake holes
