MAINTENANCE
37
ob01518
2. Attach a water hose to the fitting. Turn on the water and flush for 3 to 5 minutes.
ob01519
Top Cowl Removal And Installation
REMOVAL
1. Pull out the front cowl latch.
ob01086
2. Lift front of cowl to clear front latch and push toward the rear to clear rear hooks.
3. Lift top cowl to remove.
INSTALLATION
1. Lower top cowl into position over engine.
2. Move the cowl toward the rear to align rear hooks. After rear hooks have engaged, move cowl toward front
and push down front of cowl.
3. Push in latch to secure top cowl.
Exterior Care
Your outboard is protected with a durable baked enamel finish. Clean and wax often using marine cleaners and
waxes.
Fuel System
!
WARNING
Avoid serious injury or death from gasoline fire or explosion. Carefully follow all fuel system service instructions.
Always stop the engine and do not smoke or allow open flames or sparks in the area while servicing any part
of the fuel system.
