Mercury 200 Operation And Maintenance Manual

MAINTENANCE
42
ob00377
5. Pull propeller straight off shaft. If propeller is seized to the shaft and cannot be removed, have the propeller
removed by an authorized dealer.
6. Coat the propeller shaft with Quicksilver or Mercury Precision Lubricants Anti‑Corrosion Grease or 2‑4‑C
with Teflon.
ob00378
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion Grease Propeller shaft 92-802867Q1
95
2-4-C Marine Lubricant
with Teflon
Propeller shaft 92-802859Q1
IMPORTANT: To prevent the propeller hub from corroding and seizing to the propeller shaft (especially in salt
water), always apply a coat of the recommended lubricant to the entire propeller shaft at the recommended
maintenance intervals and also each time the propeller is removed.
7. Flo‑Torq I Drive Hub Propellers ‑ Install forward thrust hub, propeller, continuity washer, rear thrust hub,
propeller nut retainer, and propeller nut onto the shaft.
ob00382
a
b c
d
e
f
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Continuity washer
e - Propeller
f - Forward thrust washer
8. Flo‑Torq II Drive Hub Propellers ‑ Install forward thrust hub, replaceable drive sleeve, propeller, thrust hub,
propeller nut retainer and propeller nut onto the shaft.

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
