FEATURES AND CONTROLS
19
Features & Controls
Throttle Grip Friction Knob - Turn friction knob to set and maintain the throttle at desired speed. Turn knob up to
tighten friction and down to loosen friction.
a - Direction to tighten friction b - Direction to loosen friction
Choke Knob - Pull completely out when starting a cold engine. Push halfway in as engine is warming up. Push in
completely after engine is warmed up.
Steering Friction Adjustment - Adjust this knob to achieve the desired steering friction (drag) on the tiller handle.
Turn knob clockwise to tighten friction and counterclockwise to loosen friction.
a - Tighten friction b - Loosen friction
WARNING
Avoid possible serious injury or death from loss of boat control. Maintain sufficient steering friction to prevent
the outboard from steering into a full turn if the tiller handle or steering wheel is released.
Two Way Fuel Valve - Turn valve up when using a remote fuel tank. Turn valve down when using the internal fuel
tank.
